Product Description
Vanquish 560 represents the top standard in the Vanquish 60 line, with greater power, accuracy and control. It relies on Multi-IQ technology to detect across several frequencies at once, for precise target response and effective recovery across changing ground.
The V12X coil increases ground coverage and sensitivity, while 4 iron-bias levels, 5 target tones and in-handle vibration give you better support isolating valuable targets. The detector is fully waterproof to 5 metres (IP68), light and compact, ready for any terrain.
The monochrome red LED screen gives better visibility in low light, with low-latency Bluetooth LE audio and up to 10 hours of battery life — a professional detecting tool with intuitive operation and sharp response.
Key Features
- Multi-IQ technology: simultaneous multiple frequencies for consistent performance.
- V12X coil: greater coverage and sensitivity than the rest of the range.
- 30 discrimination segments and 4 iron-bias levels: advanced control.
- 5 target tones: finer audio separation for quick target recognition.
- Full IP68 waterproofing: safe submersion to 5 metres in any conditions.
- Bluetooth LE (LC3) audio: fast, low-latency wireless sound.
- Up to 10-hour battery: long detecting sessions without interruption.
Ideal For
- Serious detectorists wanting the best performance in the Vanquish range
- Searching parks, fields and beaches with dense trash
- Anyone wanting advanced control without a steep learning curve
- Professional hunting for coins, jewellery, relics and gold
Technical Specifications
TechnologySimultaneous multi-frequency Multi-IQ
Search ModesPark, Field, Beach, custom User Profile (4)
Pinpoint ModeYes
Noise CancelAutomatic
Sensitivity10 levels
Volume10 levels (for general audio and iron-tone response)
Target Tones5 tones for finer audio separation
Discrimination Segments30 segments
Iron Bias4 levels
Wireless AudioLow-latency Bluetooth LE (LC3) + wired headphones included
VibrationIn-handle vibration for noisy environments
DisplayMonochrome red LED with backlight + built-in flashlight
Standard Search CoilV12X elliptical 12×9-inch Double-D, high coverage
LengthExtended: 142 cm (56 in) / Folded: 79 cm (31 in)
Weight1.26 kg
BatteryInternal lithium-ion, up to 10 hours (magnetic USB-C charging)
Waterproof RatingFully waterproof to 5 metres (IP68)
Warranty3 years on detector and coil
What's in the Box
Minelab Vanquish 560 ships with everything you need to start detecting right away.
V12X elliptical 12×9-inch Double-D search coil
Wired headphones included
Magnetic USB-C charging cable
Removable armrest with strap
Comparison Table
Compare Minelab Vanquish 560 with related Minelab models.
ModelVanquish 560 / Vanquish 460 / Vanquish 560 Pro Pack
Included CoilV12X (12×9 in) only / V10X (10×7 in) / V12X and V8X together
Discrimination Segments30 / 30 / 30
Iron Bias4 levels / 3 levels / 4 levels
Target Tones5 tones / 3 tones / 5 tones
HeadphonesWired + Bluetooth LE / Wired + Bluetooth LE / ML60 wireless Bluetooth LE included
Best Suited ForTop performance with a single coil for wide coverage / Balance of simplicity and customisation / Serious hunters wanting both coverage and accuracy
